Slide Anti vibration cap Anti vibration cap Anti vibration cap for Electric Motors
Of every kind

What is the range of application?

Anti Vibration Cap
Anti Vibration Cap

HVAC

Our mount is extensively used in the HVAC sector (Heating, Ventilation and Air Conditioning).

Anti Vibration Cap

DOMESTIC APPLIANCE

Our mount is also used very successfully in a wide range of domestic appliances, such as vacuum cleaners, hair dryers and food mixers.

Anti Vibration Cap

AUTOMOTIVE

Except for very large electric motors, our mounts are also widely used for electric motors in the automotive sector (air conditioning, car window systems etc.)

What are the advantages?

Label

NOISE ABATEMENT (-20%)

Label

MOTOR SHAFT WEAR PROTECTION

Label

ENERGY SAVINGS

Label

VARIOUS MATERIALS FOR DIFFERENT APPLICATIONS

Label

REGULATORY STANDARD SIZES

Label

IMPROVED MOTOR PERFORMANCE

Anti Vibration Cap

Technical Specifications

COD         DS        DE        H        DF        S        DT            TYPE OF BEARING


135 F.C.   12.8     16.0     5.5      cieco    5.0    16.2                624


165 F12    15.8     19.0     6.0      12.0    5.0    19.1                625-634


196 F12    18.8     22.0     7.0      12.5    6.0    22.2-0.1+0     607-626


227 F17     21.8    26.0     8.0      17.0    7.0    26.2                608-62


268 F16     25.8    30.0     9.5      16.0    8.0    30.2+-0.1       6000-629


268 F20     25.8    30.0     9.8       20.0   8.0    30.1+-0.1       6000-629


288 F23     27.8    32.0     9.5       23.0   8.0    32.1+-0.1       6001


309 F18     29.8    34.0     10.5     18.2   9.0    34.2                6200


3210 F20   31.8    36.2     11.5      20.0  10.0  36.5+-0.1       6201-6002


3511 F25   34.8    40.0     13.0      25.0   11.0  40.1+-0.1      6202-6300


4012 F25    39.7   44.7     14.0      25.0   12.0   45.2+-0.1     6203


4714 F30    46.5   51.6     16.0      30.0   14.0   52.1             6204-6303


Anti Vibration Cap

CiBiesse Gomma

We have specialised in the production of anti vibration ball bearing mounts for electric motors since 1960.

Our mounts are particularly suited for electric motors from 4,000 to 30,000 rpm and guarantee silent operations, protection and energy savings.

We use our own moulds and make it possible to receive a free sample delivery of our mounts so you can test them on your motors before placing an order.
The table to the side provides a list of the standard sizes available.

In 2011 CiBiesse Gomma was taken over by PuntoGomma Snc, a company specialised in the manufacturing of technical vulcanised rubber articles to customer specifications and is an ISO UNI EN ISO 9001:2008 Certified company.

CiBiesse Gomma currently operates in the Sebino rubber-manufacturing district, specialising in the manufacturing of moulded rubber products, and one of the major rubber-manufacturing districts in Europe.

Anti Vibration Cap

Cod.                268


Bearing          6000/629


Material         NBR


Sizes               De 30.0 H 9.5 Ds 25.8 Df 16

Anti Vibration Cap

Cod.                268 foro 20


Bearing          6000/629


Material         NBR


Sizes              De 30.0 H 9.8 Ds 25.8 Df 20.0

Anti Vibration Cap

Cod.                22717


Bearing          608/627


Material        NBR – SILICONE rosso –
                       NBR dielettrica verde


Sizes              De 26.0 H 8.0 Ds 21.8 Df 17.0

Anti Vibration Cap

Cod.                3210


Bearing         6201/6002


Material        NBR dielettrica verde


Sizes             De 36.2 H 11.5 Ds 31.8 Df 20.0

Anti Vibration Cap

Cod.               28×8


Bearing         6001


Material        NBR


Sizes              De 32.0 H 9.5 Ds 27.8 Df 23.0

Anti Vibration Cap

Cod.                196


Bearing          607/626


Material         NBR – HNBR – SILICONE rosso – NBR dielettrica verde


Sizes               De 22.0 H 7.0 Ds 18.8 Df 12.5

Anti Vibration Cap

Cod.                16×5


Bearing          625/634


Material        NBR


Sizes             De 19.0 H 6.0 Ds 15.8 Df 12.0

Anti Vibration Cap

Cod.                13×5


Bearing          624


Material        NBR


Sizes             De 16.0 H 5.5 Ds 12.8 Df cieco

Anti Vibration Cap

Ammortizzatore           Nero


Material                         NBR


Durezza                         SHORE60

Anti Vibration Cap

Ammortizzatore           Verde


Material                         NBR


Durezza                         SHORE50

CiBiesse Anti Vibration Mounts

We export all over the world

Cibiesse Gomma

Dal 1960 siamo specializzati nella produzione di antivibranti copri cuscinetto a sfera per motori elettrici.

Le nostre calotte sono particolarmente adatte per motori elettrici da 4000 a 30.000 giri/minuto e garantiscono silenziosità, protezione e risparmio energetico.
Utilizziamo stampi di proprietà ed diamo la possibilità di ricevere una campionatura gratuita delle nostre calotte in modo da poterle testare sui vostri motori prima dell’acquisto.
Nella tabella a fianco trovate l’elenco delle dimensioni standard disponibili.
